The Standard Black tiles are designed for the Cool Colour paint coating to be applied. The Standard Black tiles are factory fabricated with computer controlled thickness of 15mm or 20mm.
The Standard Black tile laid in conjunction with soft fall rebound protection underlay tile is its foundation for impact attenuation; this base system offers consistency in thickness, density, and resiliency.
The Standard black tiles are installed in brick pattern and all seams are sealed and bonded with a tough, abrasion resistant polyurethane construction adhesive on site then painted with the cool colour paint coating.
Use the Softfall rebound protection underlay in conjunction with the standard black tiles to ensure compliance with Australian Standards. (See Fall Height Graph to determine correct thickness required).
The Cool Colour Paint surface system conforms to Australian Draft Standards AS/NZS 4422/96 when site tested. The product comes with independent laboratory test results showing conformance to these requirements at the fall height specified by the purchaser on both the body and seams of the product.
